Waterway OASIS six-function pool and spa controller with a removable user interface, optional Wi-Fi and valve-actuator packages, four schedules per assigned function, and support for Waterway and selected third-party variable-speed pumps.
| Connectivity | |
|---|---|
| Circuits | Six-function controller |
| Protocol | Optional OASIS Wi-Fi; 2.4 GHz network required |
| Compatible Controls | Waterway WWVSP/WWVSP2, Pentair IntelliFlo, Hayward EcoStar, and Jandy Pro Series VSP selections documented in the manual |
| Events | Four user schedules per assigned function |
| Operation Mode | Pool, spa, and spillover modes; 3-hour Service Timeout; 24-hour Service Mode; configurable freeze protection |
| Package Variants | 770-1006-PSW2: Wi-Fi and two valve actuators; 770-1002-PS2: two valve actuators; 770-1004-PSW: Wi-Fi; 770-1000-PS: base package |
| Electrical | |
| Voltage | 120 or 240 VAC |
| Frequency | 60 Hz |
| Current Draw | 1.67 A controller supply |
| Load Ratings | High voltage: 25 A; 3 HP at 240 V or 1.5 HP at 120 V; 1500 W incandescent. Low voltage: Class 2, 1 A at 24 VAC |
| Physical | |
| Installation Location | At least 5 ft from the pool or spa and 5 ft above ground; Canadian installations at least 3 m / 9.8 ft from the water |
| Wi-Fi Placement | Wi-Fi module at least 10 ft from motors or heavy electrical equipment; router-to-module distance no more than 100 ft recommended |
