What salt level does the CMP PowerClean Salt Econ need?

The recommended salt level is 4,000-4,500 ppm.

What voltage does the CMP PowerClean Salt Econ require?

The CMP PowerClean Salt Econ operates on Factory wired for 220V; field-convertible to 120V.

Common error codes include: No AC Power, Low Chlorine Output. See the troubleshooting section for details on each.

Chlorination
Recommended Salt Level	4,000-4,500 ppm
Salt Level Range	Operates down to 3,000 ppm
Electrical
Voltage	Factory wired for 220V; field-convertible to 120V
Physical
Horizontal Clearance	Install control center at least 10 ft from inside pool walls.
Flow Switch	Internal electronic flow sensing tab shuts off cell power when flow stops.

Manual uses the same clear 4,000 to 4,500 ppm ideal salt target as PowerClean Ultra.
Control center ships wired for 220V and can be converted to 120V.
Manual documents power, cell condition, and chlorine-output troubleshooting paths.

No AC Power

Manual troubleshooting includes checking AC power to the control center.

Low Chlorine Output

Manual troubleshooting includes salt level, runtime/output setting, pool chemistry, and cell condition.

Part	Part Number	Description
PowerClean Salt Replacement Cell	`52000-220-110`	20,000 gallon replacement cell listed in the manual.
PowerClean Salt Extended Life Replacement Cell	`52000-220-160`	20,000 gallon extended life replacement cell listed in the manual.
