What are the common error codes on the CMP DEL AOP-S?

Common error codes include: System Active Indicator Off, Ozone Tube Deterioration. See the troubleshooting section for details on each.

CMP DEL AOP-S Specs, Parts & Error Codes

Electrical
Switch Type	Connect to pool timing clock so the system operates with the pool pump.
Breaker Size	Manual calls for GFCI protection.
Performance
Min Flow (GPM)	5 GPM
Max Flow (GPM)	20 GPM
Physical
Plumbing Connection	Recommended dedicated pool return from the DEL AOP-S; if unavailable, connect back to the main pool return downstream of all equipment.
Flow Switch	Manual troubleshooting references minimum 5 GPM injector flow for active operation.

Manual gives a narrow 5 to 20 GPM flow range for sizing the bypass or return path.
Uses replaceable UV lamp and ozone module assemblies.
Can connect to a dedicated return or downstream main return depending on plumbing options.

System Active Indicator Off

Manual checks include pool system operation and minimum 5 GPM injector flow.

Ozone Tube Deterioration

Manual flags yellow, brown, or brittle ozone tubing as a service condition.

Part	Part Number	Description
UV Lamp Replacement Assembly	`9-1100-01`	Replacement UV lamp assembly listed in the manual.
Ozone Module	`9-1636-01`	Replacement ozone module listed in the manual.
