What are the common error codes on the Waterway Spa Skimmer?

Common error codes include: Low Skimmer Flow, Excess Skimmer Flow, Incorrect Water Level. See the troubleshooting section for details on each.

Waterway Spa Skimmer Specs, Parts & Error Codes

Filtration
Filter Type	Adjustable-flow spa surface skimmer
Flow Adjustment	Remove the basket; turn the diverter plate clockwise to increase flow or counterclockwise to reduce flow
Physical
Plumbing Connection	2 in. spigot and 1.5 in. socket connections
Water Level	Water level should be at the midpoint of the wall opening
Opening Dimensions	Manual hole-pattern drawing includes 5 7/8, 6 7/8, 5 1/8, and 2 3/4 in. dimensions
Trim Variants	Plastic trim plate; optional stainless-steel trim plate and optional mounting plate

Flow can be adjusted from inside the basket opening.
The installation drawing documents both 2-inch spigot and 1.5-inch socket plumbing.
Plastic and optional stainless-steel trim arrangements are shown.

Low Skimmer Flow

Remove the basket and turn the diverter plate clockwise to increase flow.

Excess Skimmer Flow

Remove the basket and turn the diverter plate counterclockwise to reduce flow.

Incorrect Water Level

Adjust fill level so water is at the midpoint of the wall opening.

Part	Part Number	Description
Optional Stainless-Steel Trim Plate	`216-1010`	Stainless trim option identified in the installation drawing.
Optional Mounting Plate	`519-3200`	Mounting plate supplied with ten machine screws.
