Raypak

XTherm 1005A-2005A

Commercial Gas Heater

Manual-backed spec and service reference for Raypak XTherm 1005A-2005A commercial boiler/water heater/pool heater models.

Raypak XTherm 1005A-2005A
999,000 - 1,999,000 BTU/hr
BTU Range
Natural Gas or Propane
Gas Type
120 VAC
Voltage

Specifications

Heating
BTU Range999,000 - 1,999,000 BTU/hr
Gas TypeNatural Gas or Propane
Electrical
Voltage120 VAC
PhaseSingle phase
Frequency60 Hz
Performance
Min Flow NotePool flow and bypass requirements are model- and installation-specific; verify against the source manual tables.
Certifications
CSA CertifiedYes

Pros & Cons

Pros

  • Manual includes commercial installation, controls, wiring, venting, startup, maintenance, and parts sections.
  • Covers pool heater Type P configurations alongside hydronic and domestic hot water variants.
  • Useful for large commercial pool equipment rooms.

Watchouts

  • Commercial combustion, venting, gas-train, and code requirements are materially more complex than residential heaters.
  • Confirm Type P pool configuration and exact model before using specs.
  • Public spec page should not replace engineered sizing or licensed installation review.
