The Pentair UltraTemp is an energy-efficient heat pump for pool and spa heating, available in capacities from 75,000 to 145,000 BTU/h. It uses a titanium heat exchanger and R-410A refrigerant, with select models offering both heating and cooling capability.
| Heating | |
|---|---|
| BTU Range | 75,000 - 145,000 BTU/h |
| Refrigerant | R-410A |
| COP (Efficiency) | 4.0 - 6.1 (varies by conditions) |
| Electrical | |
| Voltage | 208-230V, 1 or 3 phase, 60 Hz |
| Min Amps | 33A |
| Max Amps | 43A |
| Breaker Range | 40-50A |
| Performance | |
| Min Flow (GPM) | 30 GPM |
| Max Flow (GPM) | 120 GPM |
| Max Pressure | 50 PSI |
| Physical | |
| Inlet Size | 2 in PVC (unions included) |
| Outlet Size | 2 in PVC (unions included) |
| Certifications | |
| ETL Listed | Yes |
