Jandy JXi & LXi Heater Error Code Reference

Model Coverage: These codes apply to both the Jandy JXi (Model 200, 260, 400) and LXi (Model 250, 400) gas-fired heaters. The LXi displays "NO FLOW" instead of "CHECK FLOW."

Disclaimer: This tool provides general guidance based on published Jandy specifications and common troubleshooting patterns. It is not a substitute for professional diagnosis. Manufacturer specifications may vary by model and firmware version. Always consult your model's owner manual and a licensed pool service professional for repairs.

Understanding Jandy JXi & LXi Error Codes

The Jandy JXi and LXi are premium gas-fired pool and spa heaters manufactured by Fluidra (formerly Zodiac). The JXi series includes the JXi 200, JXi 260, and JXi 400 models, while the LXi series covers the LXi 250 and LXi 400. Both lines use a combination of LED status indicators on the ignition control module and digital display fault messages to communicate operating status and error conditions.

The JXi and LXi heaters communicate faults in two ways: LED flash patterns on the ignition control module inside the heater, and text-based fault messages on the front display panel. LED codes typically indicate ignition and combustion issues, while display messages cover a broader range of water flow, sensor, and system faults.

How the Diagnostic System Works

During normal operation, the JXi/LXi display shows the current water temperature and set point. When a fault is detected, the display shows a text message describing the condition. For ignition-related faults, the LED on the ignition control module inside the heater flashes in specific patterns (single flash, double flash, triple flash) to indicate the type of problem. Some faults trigger a soft lockout that auto-resets after one hour, while others require manual intervention or professional service.

When to Call a Professional

While some error codes have straightforward fixes a homeowner can attempt, many situations require a licensed pool service technician or gas professional:

Any gas-related issue -- If you smell gas, see a "flame exists when no call for heat" LED pattern, or experience repeated ignition failures, shut off the gas supply and call a professional immediately.
High limit or flue temperature faults -- These critical safety codes indicate the heater is overheating and may have flow or venting problems that need professional diagnosis.
Repeated ignition lockouts -- If the heater repeatedly enters lockout after three failed ignition attempts, there is likely a gas supply, igniter, or fan issue that needs professional attention.
Sensor failures -- Shorted or open water temperature sensors require replacement parts and proper calibration.
Ignition control faults -- A continuous LED on the ignition module indicates an internal controller failure that requires module replacement by a qualified technician.

Jandy JXi & LXi Error Code FAQs

What does "CHECK FLOW" mean on my Jandy JXi heater?

CHECK FLOW means the water pressure switch inside the heater has detected insufficient water flow. The most common causes are a pump that is not running, a dirty filter restricting flow, or a variable speed pump running too slowly. Verify your pump is running and fully primed, clean or backwash your filter, and if you have a VS pump, increase the speed during heating cycles. On the LXi, this same condition displays as "NO FLOW."

Why does my Jandy heater LED flash three times and not ignite?

A triple-flash LED pattern indicates the heater has entered ignition lockout after three unsuccessful attempts to fire. Common causes include low gas supply, a broken or weak igniter, air in the gas line, or the gas valve being in the OFF position. The heater will automatically retry after one hour. Check that your gas supply is on, verify the gas valve is in the ON position, and inspect the igniter for damage. If the problem persists after several retry cycles, call a service technician.

Is the "double flash" LED code on my Jandy heater dangerous?

Yes, a double-flash LED is a critical safety code meaning flame is detected when the heater should not be firing. This could indicate a gas valve that is not closing properly or a flame sensor malfunction. Turn off the heater immediately and do not attempt to restart it. Contact a qualified service technician right away. Do not operate the heater until it has been professionally inspected.

What does "FAULT-HIGH LIMIT" mean and how do I fix it?

FAULT-HIGH LIMIT means the water temperature inside the heater has exceeded the internal safety limit. This is typically caused by insufficient water flow through the heater, a blocked vent, or a faulty limit switch. Check that your pump is running at adequate speed, clean or backwash the filter, and inspect the exhaust vent for obstructions. If the fault keeps recurring, the limit switches may need replacement by a service professional.

How do I reset my Jandy JXi or LXi heater after an error?

For most display fault messages, you can reset the heater by turning it off at the control panel, waiting 30 seconds, and turning it back on. For ignition lockout (triple-flash LED), the heater auto-resets after one hour, or you can power-cycle it at the breaker to reset immediately. For critical faults like high limit or flue temperature errors, always address the underlying cause before resetting. If the same error returns after resetting, professional diagnosis is needed.
