Interactive diagnostic wizard for Pentair FNS Plus vertical grid DE filters. Diagnose high pressure after backwash, DE powder in pool, short filter runs, air in the system, and grid damage.
Select the symptom your filter is showing to get step-by-step troubleshooting guidance.
Click a symptom to see diagnostic steps.
This interactive troubleshooting wizard is designed specifically for the Pentair FNS Plus vertical grid DE (diatomaceous earth) pool filter. Whether you are a homeowner seeing DE powder in your pool or a service technician diagnosing persistent high pressure after backwash, the wizard adapts to your role and provides the appropriate level of guidance.
Select the "Homeowner" role for safe, practical checks you can perform yourself, or switch to "Technician" mode for detailed diagnostic procedures including grid inspection, manifold assessment, and acid cleaning. Each symptom card links to comprehensive guidance when you need to go deeper.
The table below summarizes the most common Pentair FNS Plus DE filter issues. Click the troubleshooter above for step-by-step diagnosis of each symptom.
| Symptom | Description |
|---|---|
| High Pressure After Backwash | Pressure remains elevated even after a full backwash cycle — grids may need cleaning or have mineral buildup |
| DE Powder in Pool | Diatomaceous earth continuously enters the pool through return jets — torn grids or damaged air bleed |
| Air in System | Bubbles at return jets, low pump pot water level, air discharges from manual relief valve |
| Short Filter Runs | Pressure climbs rapidly between backwashes, requiring frequent cleaning |
| Low / Dropping Pressure | Gauge drops toward zero or reads abnormally low while pump runs |
| Grid Liming (Mineral Buildup) | Stiffened grid fabric caused by calcium or magnesium deposits, reducing filter efficiency |
| Dirt Cloud at Startup | Brief cloud of dirty water appears in pool immediately after filter starts |
| Filter Leaking | Water leaks from clamp area or union connections during operation |
DE powder entering the pool is typically caused by a torn or damaged grid element inside the filter. Open the filter and inspect each grid for tears, holes, or deteriorated fabric. Also check the internal air bleed sock for tears and verify it is properly installed. Even a small tear in one grid will allow DE to pass through and enter the pool through the return jets.
Liming refers to a stiffening of the grid fabric caused by mineral deposits, usually calcium or magnesium. This reduces flow through the grids and causes pressure to remain high even after backwashing. To remove liming, soak the grids in a solution of six parts water to one part muriatic acid. Always wear rubber gloves, safety glasses, and work in a well-ventilated area when handling acid.
Yes. A brief cloud of dirt appearing immediately when the filter starts is a normal characteristic of diatomite filters. The initial surge of water dislodges a small amount of residual material before the DE coating fully seals against the grids. If the cloudiness persists beyond the first minute or two, that indicates a different problem such as torn grids or insufficient DE coating.
Prepare a slurry of diatomaceous earth and water in a bucket. With the pump running and the filter assembled, slowly pour the slurry into the skimmer. The pump will draw the DE into the filter and coat the grids evenly. Refer to your specific model's manual for the exact amount of DE required — using too little leaves grids exposed and allows dirt to pass through, while too much can restrict flow prematurely.
If pressure remains high after backwashing, try backwashing again for a longer duration. If it is still high, the grids likely have mineral buildup (liming) that backwashing alone cannot remove. You will need to manually clean the grids by opening the filter and hosing each grid individually, or perform a muriatic acid soak to dissolve calcium and magnesium deposits.
Yes. Select the "Homeowner" role and the wizard will show only the checks that are safe and practical for a non-professional to perform. Technician-level steps such as grid inspection, manifold disassembly, and acid soaking are hidden unless you switch to Technician mode. Always follow the safety warnings on screen, and consult a licensed pool service professional for any repair you are not comfortable performing.
